Axxess AX-LOC4.4-PRO 4-Channel 40V IN Active Line Output Converter w/ Bass Boost

BRAND NEW

AXXESS AX-LOC4.4-PRO

4-Channel 40V Input Active Line Output Converter w/ Bass Boost

Key Features:

• 4-channel active LOC with bass boost for OEM source integration
• Line driver functionality
• 40V / 400W maximum input level at 20k ohm
• Remote, DC, or audio trigger selection
• Generated remote output rated at 500mA
• 20 / 60 / 20k ohm input impedance selection
• Ground selection: GND / ISO / 200 ohm
• Independent front/rear gain adjustment
• Low-pass filter and bass boost on rear channels
• Optional AX-RM1 remote control support

Specifications:

• Brand: Axxess
• Model: AX-LOC4.4-PRO
• Product Type: 4-channel active line output converter with bass boost
• Application: Universal amplifier addition / OEM source integration
• Compatibility Type: Universal
• Channel Configuration: 4-channel: 4 in / 4 out
• Input / Output: Speaker-level input to RCA preamp output
• Max Input Level: 40V / 400W @ 20k ohm
• Operating Voltage: 9V-16V
• Remote Output Rating: 500mA
• Output Max at 13.8V: 9.5V RMS
• Gain Adjustment: -28dB to +1dB
• Input Sensitivity: 0.5V-20V
• Frequency Response: 20Hz-20kHz
• Bass Boost: 0dB to +12dB on rear channels
